IR-06221

PIR SENSOR (Split mounted)

Feature
● Adopt advanced imported internal sensor and circuit design, less in false or missing action
● The lamp lights on while people approaches sensing area, lamp turn off while object leave the sensing area
● Time delay, photosensitivity adjustable
● Easy installation for ceiling or hanging mode
● Can identify day and night: The consumer can adjust work ambient light. It can work in the daytime and at night when it is adjusted on the “sun”  position (max).
     It can work in the ambient light less than 3LUX when it is adjusted on the “moon” position (min).
● Connection: wiring type 2 in & 2 out
● Spilt type, sensing head and body separately .Any fixtures or luminaries are available, such as tungsten lamps, fluorescent lamps, compact fluorescent lights, LED lights, etc.

Applications
● Used for corridor, storage, balcony, garage, lamp automatic turn-off places
